ML-1225 TECHNICAL INFORMATION
Power supplies:
115/230V 50/60 Hz
Lamp:
OSRAM SIRIUS HRI 230W
Color temperature:
8,000k
Average life:
2000 hrs
Control channels :
2 DMX protocol modes
16/20
Display :
Blue/white LCD graphic
Color wheel:
Interchangeable color wheel
with 14 colors +open
Gobo wheel:
Interchangeable gobo wheel
with 17 fixed gobos +open
Adjustable beam angle from: 0 to 3.8°
•High speed shake effect
•8-facet rotating prism
•Frost filter
Mechanical:
shutter and adjustable speed strobe effect
Mechanical dimmer
Selectable 16 bit pan/tilt movement
resolution
Pan:
540°; Tilt:252°
Motor:
Pan/Tilt used 3-phase 1.2°
ENCAPSULATED STEPPING MOTOR
Maximum speeds:
•PAN=2.10 sec
•TILT=1.20 sec
Resolution:
•PAN=2.11°
•PAN FINE=0.008°
•TILT=0.98°
•TILT FINE=0.004°
IP rating:
IP 20
Net weight:
17.5kg
